Operational Approach and Steps of the shrink wrapping machine

1. Turn on the power switch, and the shrink wrapping machine will be in the energized state;

2. Connect the air supply and adjust the air pressure to 6.0～8.0Gg /cm2；

3. Press the control button of transverse sealing and edge sealing thermostat, and adjust the temperature of transverse sealing to 160～180℃ and the temperature of edge sealing to 160～180℃；

4. Choose proper packaging materials according to the specifications of on-demand packaging products. (Calculation formula, height + width+“4～6”）；

5. Put the required packaging products to the hypotenuse triangle place of feeding conveyor line. Adjust the triangle to 5-8 mm above products, and then put the side limit strip 5-8 mm away from products so as to keep the products running smoothly in the feeding conveyor line. No stagnation is more appropriate；

6. Taking the side limit strip as a benchmark, adjust the feeding conveyor line in front of edge sealing cover. The situation depends on the product allowance;

7. According to the height and shape of the products, choose the proper detection methods for products.（Horizontal photoelectric; Vertical photoelectric）；

8. According to the direction of sketch, put the packaging materials in sequence to the position of film dragging belt. Touch the film dragging button to make the machine run, and press the sealing and cutting knife to work at the same time. After removing the waste film, pull it into the reel according to film collecting sketch;

9. After shifting the operation interface to automatic menu, launch automatic operation mode. After putting required packaging products, check whether the before and after allowance is appropriate. Adjust it in the parameter setting menu until the machine can be put into batch production.

10. Turn off the heating button, power supply and air supply after work.
